• Overlay with AIS targets.

• Able to Zoom-In the selected special target area.

• Strengthened ability to display short range targets.

• Able to choose color brightness in 10 levels for navigation at night.

• Can choose the screen color within white, yellow, green.

• Intermittent Tx mode : can operate with low electricity consumption.

• Dynamic cursor speed with 8 directional keys adopted.

• Can move screen center point and observe the long distance of the desired direction.

• Display parallel line : Can maintain certain distance between other vessel.

▶ ANTENNA

• Type : Bar-type antenna

• Output power : 6KW

• Tx frequency : 9410±30MHz

• Revolution : approx. 24rpm

• Beam width : Horizontal 2.0°/ Vertical 25°

• Synchronism method : Automatic / Manual switch over

• Operation temperature : -25℃~+55℃

• Relative humidity : 35℃~95%

• Relative wind velocity : 51.5 m/sec(100 Knots)

▶ DISPLAY UNIT

• Display unit : 10.4” Color VGA TFT LCD, Vertical display

• Resolution : 640×480

• Indication type : scan type

• Distance range : 0.0625, 0.125, 0.25, 0.5, 0.75, 1, 1.5, 2, 3, 6, 12, 24, 36, 48, 64, 72nm

• Minimum distance : within 25m

• Azimuth accuracy : within ± 1°

• Azimuth resolving power : 2.1°

• VRM : .000 ~ 72NM display in digital

• EBL : 000° ~ 359° display in digital

• Indication of bow : electronic type

• Display mode : head-up, north-up, course-up

• Operation temperature : -15℃ ~ +55℃

• Pre-heat time : approx. 90 sec.

• Input data : NMEA 0183(2port), AIS(RS-422)

• Consumption power : 85W

• Power supply : DC +24V
